Sub-Zero reference · Denver, CO
EC 07 records that the freezer compartment sensor read open, shorted or unsteady for long enough that the control stopped trusting it. Sub-Zero Pro Repair Denver takes that reading before the compressor is blamed — (720) 704-2791.
Sub-Zero Pro Repair Denver — (720) 704-2791
Built-In 600-3 Series panels, which carry the numbered code table
Sub-Zero publishes two actions against this code and no more: connections and continuity back to J1, then resistance at the sensor, with a replacement only where the figure sits outside the window.
The short list matters more than its length suggests. This is the sensor the control judges the whole freezer by, and the first stop on the manufacturer’s route through an excessive freezer run. A sealed system diagnosed through a lying thermometer is a sealed system diagnosed twice.
EC 40 stored on the cabinet with this entry underneath it
The route through the freezer run-time code opens at 07, long before the compressor is mentioned. A control told a compartment is still warm has no reason to stop cooling it.
Defrost circuit: heater, terminator, thermistor $280–$690
EE in the freezer slot, the fresh-food side perfectly normal
Each half of a built-in is measured through its own sensor and its own location code. One can lose that measurement while the other reports as usual.
No band covers this one — quoted after the diagnosis
A sensible figure on the panel and a compartment softening anyway
The number is only as good as the part producing it, which is why the coil gets a reading of its own before anything is quoted.
Defrost circuit: heater, terminator, thermistor $280–$690
There is more slack here than on the fresh-food side: a full freezer carries its own cold for a time. But the compartment now runs on a figure the control has itself flagged, and the entry will not lapse. Read it, correct it, then clear it — in that order.
Where this sits
Bench notes from
Tobias Reinhardt
Checked against
Sub-Zero Built-In (600-3) service manual #7003192 Rev C: Error Code Table p. 8-2, Error Code Troubleshooting Guide pp. 8-3 and 8-4, General Troubleshooting items B and G
Reading it with you
Tell us what the panel is showing and we will tell you what we would measure first. Sub-Zero Pro Repair Denver — (720) 704-2791. On the road 8:00 am – 8:00 pm, seven days.
Describe the symptom on the phone and you will usually hear what it probably is before anyone drives out. A $89 service call covers the visit and the full diagnosis in Denver, and comes off the repair once you approve it.
