Sub-Zero reference · Denver, CO
EC 06 names the sensor clipped to the refrigerator's evaporator, not the one behind the number on the door. Sub-Zero Pro Repair Denver confirms it under the letters rE in Diagnostic Mode — (720) 704-2791.
Sub-Zero Pro Repair Denver — (720) 704-2791
Built-In 600-3 Series control, confirmed through Diagnostic Mode
The distinction this code draws is the whole of it. A built-in carries one sensor in the fresh-food air and a second on the coil behind the rear wall. EC 06 is the second, and nothing on the front of the cabinet reports it.
So the confirmation moves inside. The location table files the refrigerator evaporator under rE, and EE in that slot is the control admitting it cannot use what it receives.
SERVICE lit on a cabinet holding both of its set points
Sub-Zero files this sensor under exactly that heading — warm or normal temperatures with SERVICE alone flashing. Nothing in the kitchen changes, so the confirmation happens in Diagnostic Mode rather than by eye.
Defrost circuit: heater, terminator, thermistor $280–$690
EE where the rE value should be when the readings are stepped through
The control saying it cannot use what the coil sensor sends. It is the fastest confirmation on this code, and it costs nothing but a key sequence.
No band covers this one — quoted after the diagnosis
EC 50 stored alongside it on a fresh-food side that never settles
Cause and consequence filed as two entries. The route through that run-time code begins at 05 or 06, because refrigeration cannot be judged through a sensor that is not reporting.
Defrost circuit: heater, terminator, thermistor $280–$690
Often, yes. The compartment is still steered by its cabinet sensor, a separate part on a separate circuit, so food is rarely the first casualty. What has gone is the control's read on the coil — and on a not-cooling call that is the view we want back before anyone raises the sealed system.
Where this sits
Bench notes from
Tobias Reinhardt
Checked against
Sub-Zero Built-In (600-3) service manual #7003192 Rev C: Error Code Table p. 8-2, Thermistor Location Code Tables p. 8-5, General Troubleshooting items D and K
Reading it with you
Tell us what the panel is showing and we will tell you what we would measure first. Sub-Zero Pro Repair Denver — (720) 704-2791. On the road 8:00 am – 8:00 pm, seven days.
Describe the symptom on the phone and you will usually hear what it probably is before anyone drives out. A $89 service call covers the visit and the full diagnosis in Denver, and comes off the repair once you approve it.
